ID # 23552293 2023 Yamaha YZ65
MOTOCROSS DREAMS START HERE- Designed for the discriminating mini moto racer that wants to win and propel themselves into the victory zone, the Yamaha YZ65 offers youth riders with the same top-notch performance and reliability of bigger YZ models.
Engineers designed the YZ65 for kids stepping between 50 and 85 cc dirt bikes. Manageable power from the 65 cc two-stroke engine, a miniaturized frame, smaller wheels (compared to the YZ85) and light overall weight are all features designed to allow youth riders to ride faster with confidence.
The YZ65's liquid-cooled, two-stroke, single-cylinder engine features the Yamaha Power Valve System (YPVS), providing excellent power and torque characteristics. The same advanced technologies found in Yamaha's race-winning YZ125 and YZ250 motocrossers can also be found in the YZ65.
The YZ65 draws upon Yamaha's decades of leading track performance and proven durability. Adjustable front and rear suspension, a tapered handlebar and YZ450F-inspired bodywork are just a few of the trickle-down highlights of the smallest YZ model.
features and benefits
Features & Benefits
KEY FEATURES Powerful-feeling 65 cc liquid cooled, single-cylinder 2-stroke engine with Yamaha Power Valve System (YPVS) Crankcase reed valve 6-speed transmission with optimized gear ratios Semi-double-cradle steel frame, aluminum subframe 36 mm inverted fork with 12 levels of compression and 10 levels of rebound damping for solid front-end feedback Monocross rear suspension with 10 levels of adjustment for both rebound and compression damping Aluminum swingarm Aluminum tapered handlebar with four positions of adjustability 14-inch front and 12-inch rear wheel Styling based on high-end YZ models
Powerful-feeling 65 cc single-cylinder, liquid-cooled, 2-stroke engine with crankcase reed valve. Overall design creates excellent ride character and performance
Yamaha Power Valve System (YPVS). Mechanical power valve system delivers effective exhaust timing throughout the entire rev range Provides excellent power and torque characteristics Delivers responsive acceleration just as the rider intends Slit-shaped valve on the side of the exhaust port operates in response to engine rpm In low-to-mid-rpm range when exhaust timing is slower, valve moves to cover the top part of the exhaust port In high rpm range when quick exhaust timing is needed, valve recedes and exhaust port is fully uncovered Valve control governor from YZ125 and YZ250 employed
2-petal reed valve.
Optimized crankshaft balance and lightweight connecting rod. Resin weight in crank web creates high primary compression ratio and optimal inertial mass Delivers instant power delivery and reduced vibration
Specialized intake manifold and exhaust pipe. Optimal intake and exhaust layout complies with racing regulations Short exhaust produces rippling sound unique to a 2-stroke Expansion chamber designed for plenty of volume Design pays special attention to pulses that occur during combustion flow to contribute to explosive but easy-to-use power Exhaust complies with FIM/AMA regulations Optimized ignition output produces a stronger, more consistent spark throughout the entire rpm range
Model-specific CDI unit. Digital CDI system delivers precise spark and monitors engine speed to ensure optimal timing for excellent response
Short-type spark plug. Short design offers better service ability and performance
6-speed transmission with optimized gear ratios. Ideal number of clutch plates and spring load gives clutch lever a light pull Gear ratios fine-tuned for performance
Fine-tuned air cleaner box.
Keihin PWK28 carburetor with revised settings (compared to YZ85).
Downsized radiator (compared to YZ85). * Drive chain with new dimensions (compared to YZ85). Gold colour contributes to bike's serious racing aesthetic
Semi-double-cradle steel frame and aluminum subframe. Dimensions, rigidity balance and synergy with suspension equals handling that feels light and stable, and willing to lean over in turns Lightweight, bolt-on aluminum subframe contributes to mass-centralization
Inverted 36 mm KYB front fork with 215 mm (8.5 in) of wheel travel. Design combines handling with a light, stable feel and a solid connection to the ground 36 mm inner tubes ensure planted feeling when entering corners and excellent shock absorption when going over bumps Outer tubes made of aluminum alloy for excellent rigidity and front-end feel Adjustable compression (12 levels) and rebound (10 levels) damping to fine-tune handling and performance on the track Aluminum steering stem developed for rigidity balance
KYB link-less Monocross rear suspension with 270 mm (10.6 in) of wheel travel. Design provides smooth damping feel and doesn't bottom out when absorbing shocks Shock absorber has 10 levels of adjustment for both rebound and compression damping to fine-tune handling and performance
Aluminum swingarm. Rigidity balance is tuned for YZ65's frame, delivering light handling feel and easy lean-in characteristics Swingarm end designed with ease of maintenance in mind Resin chain guard designed not to get caught up in ruts that the small wheel will travel through
Tapered aluminum handlebar with 4-position adjustability. Handlebar adjusts 27 mm to match a child's growth Handlebar crown made of cast aluminum for light weight and strength
Seat designed for comfort and easy maintenance. Seat design facilitates body weight transfer for enhanced on-track performance and rider confidence Single bolt under the seat cushioning makes seat removal easier
Bodywork based on high-end YZ models. Body panels have a soft, gentle look Styling follows the YZ design language of horizontal lines Colours and graphics similar to the flagship YZ450F
Wave-style disc brakes. Sporty wave-style rotors are lighter than conventional rotors and offer improved self-cleaning action in dirty conditions
14-inch (front) and 12-inch (rear) blue Excel rims with Maxxis SI tires. Maxxis SI tires offer good grip across a variety of track conditions Blue Excel rims offer high quality and race-minded looks
DETAILS Adjustable clutch and front brake levers Grippy footpegs Fuel capacity is 3.5 litres Bead lock on rear wheel Folding shift lever tip helps prevent damage features & specs
FEATURES & SPECS
KEY FEATURE Powerful-feeling 65 cc liquid cooled, single-cylinder 2-stroke engine with Yamaha Power Valve System (YPVS) Crankcase reed valve 6-speed transmission with optimized gear ratios Semi-double-cradle steel frame, aluminum subframe 36 mm inverted fork with 12 levels of compression and 10 levels of rebound damping for solid front-end feedback Monocross rear suspension with 10 levels of adjustment for both rebound and compression damping engine
2-stroke, liquid-cooled, crankcase-reed-valve single
Constant mesh, 6-speed
BORE AND STROKE
43.5 x 43.6 mm
IGNITION / STARTING
CDI / Kick
190 mm wave disc / single-piston caliper
198 mm wave disc / twin-piston caliper
Fully adjustable Monocross / 270 mm (10.6") wheel travel
Fully adjustable 36 mm inverted fork / 215 mm (8.5") wheel travel
Yamaha Racing Blue
1,140 mm (44.9")
61 kg (134.5lb)
755 mm (29.7")
3.5 litres (0.8 imp. gal.)
265 mm (10.4")
Call for Price Pricing excludes licensing and tax
